ZVA DN32

ZVA DN32
Product Overview:

ZVA DN32 Automatic Nozzle

Designed for gasoline, diesel, fuel oil, petroleum, Not suitable for viscous oils and water or solvents. Flow rate is up to 200L/m, for large vehicle, tank refueling, aircraft refueling and railroad locomotives.

Features and Benefits:
Ø It is equipped in a hold-open latch which enables blocking the lever in one of the three positions reflecting the speeds  of flow rate.
Ø Depending on the dispenser type, the nozzle is equipped with a proper guard for easy hanging and locking in the nozzle boot.
Ø It is compatible with DN 32 (1-1/2") hose.
Ø The nozzle has a 1-1/2" brass or aluminum fitting swivel.
Ø 100% Factory tested.



Material
Body Aluminum
Spout Aluminum
Swivel Brass, Aluminum
Seals Buna-N, Viton
Covers PVC

Technical Specifical
Working Pressure 0.05 - 0.6 Mpa
Flow Rate 200 L/m
Auto Shut-off sensibility 0.1 second
Spout Internal Diameter 39 mm
Intel Thread Female/Male, BSPT/NPT, 1-1/2"
Net Weight 1.76 KG
Swivel Net Weight 0.64 KG

Order Specifications
Item No. Swivel Inlet Size
ZVA DN3201 without swivel M54 × 1.5
ZVA DN3202 with swivel Female, BSP, 1-1/2"
ZVA DN3203 with swivel Female, NPT, 1-1/2"
ZVA DN3204 with swivel Male, BSP, 1-1/2"
ZVA DN3205 with swivel Male, NPT, 1-1/2"



Color Options
Black
